Lada 2 (152м²)

Рейтинг: 3.32/5 (19 Votes)
icon zoom
Main facade Rear facade
The project mansard house with a balcon:
  • Total area:152 м²
  • House dimensions:12 м х 13 м
CONSTRUCTION:
  • Foundations:Tape monolith reinforced concrete
  • Exterior Walls:Aerated concrete block 375 mm
  • Overlaps:Wooden joist, No
  • Roof:Pitched
  • Roofing:Bitumen tile
The project mansard house
Project price:
574
Buy Project
floor plan of the first floor of the house
NameSq.m
1Рortal 1.98
2Pantry 1.64
3Hallway 8.23
4Kitchen 10.7
5Living room 29.63
6Study room 12.54
7Half-bathroom 3.71
8Boiler room 4.53
Total floor area72,96
floor plan of the attic floor of the house
NameSq.m
1Staircase 5.24
2Pantry 4.67
3Corridor 6.67
4Bedroom 10.71
5Bedroom 21.62
6Bedroom 20.12
7Half-bathroom 8.63
Total floor area77,66
Input data and construction description
Parameter data
Soil carrying capacity
Foundations Tape monolith reinforced concrete
Walls Aerated concrete block 375 mm
Roofing Bitumen tile
Number of floors 2
First floor floor On the ground
Ground floor height 2.7 м
The height of the second floor 2.7 м
Overlap of the first floor Wooden joist

Project of house from aerated concrete with an attic floor with a room on the first floor and a balcon



проект частного дома с большой мансардной кровлей

Attic house with four bedrooms, a balcony and a terrace. Entrance to the house through the vestibule, which allows you to save heat in the cold season. To the right of the vestibule is the kitchen, ahead - the door to the living room. On the left is a storeroom and a staircase to the second floor. Behind the stairs is a boiler room and a bathroom. In the depth of the first floor there is a bedroom for guests or an elderly family member. The second floor consists of three spacious bedrooms, a bathroom and a dressing room. Two bedrooms provide access to the balcony. Roof - dvukhskatnaya that allows you to place solar panels on it. Heating with gas or electric boiler. It is possible to use a heat pump.

See more privat mansard house plan Beskid - 152 м2

   See other projects of privat houses
